St Thomas the Apostle Church
Elkhart, Indiana (USA)
|
Builder: |
Russell & Co, Cambridgeport, VT |
|
Year: |
1991 |
Opus: 12 |
|
|
Case |
|
Builder: |
Date: |
Materials: |
White oak |
Console type: |
Integral |
Stop controls: |
Draw knob |
Pedals type: |
|
Action |
Key: |
Mechanical, suspended |
Stop: |
Mechanical |
Temperament: |
|
Tuning (a'): |
|
No. stops: |
19 |
No. ranks: |
25 |
No. pipes: |
1268 |
Wind supply |
|
Power: |
Electrical |
Pressures (mm): |
Manual: 75; Pedal 85 |
|
Bibliography: |
The Diapason, March 1992 |
|
Comments: |
Incorporates some older pipes, rebuilt. All flue pipes are 94% lead
except case pipes which are zinc and burnished 53% tin. Great and Pedal
reeds of German baroque style, in 50% tin. Pedal Bourdon and bottom
octaves of manual flutes of wood. Swell Cromorne after Dom Bedos, 70%
tin. |
Specification
GREAT |
|
8 |
| Principal |
|
|
8 |
| Bourdon |
1-12 rebuilt |
4 |
| Octave |
|
2 2/3 |
| Nazard |
|
2 |
| Blockflöte |
|
1 3/5 |
| Tierce |
|
V |
| Mixture |
|
8 |
| Trompet |
|
SWELL |
|
8 |
| Gedeckt |
1-12 rebuilt |
8 |
| Viole |
1-12 rebuilt |
8 |
| Voix Celeste |
|
4 |
| Rohrflöte |
2 |
| Principal |
III |
| Scharf |
8 |
| Cromorne |
|
| Tremulant |
|
PEDAL |
|
16 |
| Bourdon |
8 |
| Offenbass |
1-32 rebuilt |
4 |
| Choralbass |
|
16 |
| Fagot |
|
COUPLERS |
|
8 |
| Swell to Great |
8 |
| Great to Pedal |
8 |
| Swell to Pedal |
|
